Marsriva MR-US10K-H 10kVA 10kW Online UPS

Brand	:	Marsriva
Model	:	MR‑US10K‑H
Rated Capacity	:	10 kVA / 10 kW
Output Voltage	:	208 / 220 / 230 / 240 VAC
Output Frequency	:	50 / 60 Hz ± 0.1 %
Output Harmonic Distortion	:	≤ 2 % THD (linear load), ≤ 5 % THD (non‑linear load)
Output Power Factor	:	1.0
Switching Time	:	AC Mode to Battery Mode: 0 ms; Inverter to Bypass: 4 ms (typical)
UPS Type	:	Double‑conversion On‑Line
Waveform Type	:	Pure Sine wave
Rated Input Voltage	:	208 / 220 / 230 / 240 VAC
Input Voltage Range	:	110–300 VAC (wide range, power limited at edges)
Input Frequency	:	50 / 60 Hz ± 6 Hz (default), ± 10 Hz adjustable
Input Power Factor	:	≥ 0.99
Load Efficiency (AC Mode)	:	Full load efficiency ~95–95.5 %
Load Efficiency (Battery Mode)	:	Full load efficiency ~94.8 % (with external batteries)
Battery Type	:	Lead‑acid battery (external, not included)
Battery Voltage	:	192 V (external battery bank configuration)
Charging Current	:	Settable (typically 1–12 A range depending on configuration)
Form Factor	:	Tower (or rack convertible depending on configuration)
Dimension (WHD mm)	:	460 × 190 × 615 mm (approx.; tower type)
Net Weight (kg)	:	~50–51 kg (depends on configuration)
Communication Interface	:	RS232, USB, EPO; optional SNMP / dry‑contact / maintenance connectors
Control Panel	:	Multifunction LCD status and control console
Alarm	:	Alarm every 8 s in battery mode /Alarm for low battery every second / Alarm on overload every second
Protection	:	Short‑circuit, overload, overcharge, and overdischarge protection
Operating Temperature	:	0 °C – 40 °C
Storage Temperature	:	–15 °C – 60 °C (battery: 0 °C – 40 °C)
Relative Humidity	:	20 – 95 % (non‑condensing)
Audible Noise	:	< 50 dB @ 1 m from surface

Brand

Marsriva

Model

MR‑US10K‑H

Rated Capacity

10 kVA / 10 kW

Output Voltage

208 / 220 / 230 / 240 VAC

Output Frequency

50 / 60 Hz ± 0.1 %

Output Harmonic Distortion

≤ 2 % THD (linear load), ≤ 5 % THD (non‑linear load)

Output Power Factor

1.0

Switching Time

AC Mode to Battery Mode: 0 ms; Inverter to Bypass: 4 ms (typical)

UPS Type

Double‑conversion On‑Line

Waveform Type

Pure Sine wave

Rated Input Voltage

208 / 220 / 230 / 240 VAC

Input Voltage Range

110–300 VAC (wide range, power limited at edges)

Input Frequency

50 / 60 Hz ± 6 Hz (default), ± 10 Hz adjustable

Input Power Factor

≥ 0.99

Load Efficiency (AC Mode)

Full load efficiency ~95–95.5 %

Load Efficiency (Battery Mode)

Full load efficiency ~94.8 % (with external batteries)

Battery Type

Lead‑acid battery (external, not included)

Battery Voltage

192 V (external battery bank configuration)

Charging Current

Settable (typically 1–12 A range depending on configuration)

Form Factor

Tower (or rack convertible depending on configuration)

Dimension (WHD mm)

460 × 190 × 615 mm (approx.; tower type)

Net Weight (kg)

~50–51 kg (depends on configuration)

Communication Interface

RS232, USB, EPO; optional SNMP / dry‑contact / maintenance connectors

Control Panel

Multifunction LCD status and control console

Alarm

Alarm every 8 s in battery mode /Alarm for low battery every second / Alarm on overload every second

Protection

Short‑circuit, overload, overcharge, and overdischarge protection

Operating Temperature

0 °C – 40 °C

Storage Temperature

–15 °C – 60 °C (battery: 0 °C – 40 °C)

Relative Humidity

20 – 95 % (non‑condensing)

Audible Noise

< 50 dB @ 1 m from surface

Product details of MR-US10K-H – 10kW Power Backup System Nepal

Marsriva MR‑US10K‑H

Marsriva MR‑US10K‑H is a 10 kVA / 10 kW online UPS built for mission-critical systems, data centers, and enterprise setups. It delivers pure sine wave power, instant 0ms switchover, and wide input voltage tolerance. Equipped with intelligent battery management and comprehensive protection, it ensures uninterrupted, high-efficiency backup for servers and infrastructure.

Key Features

10kVA / 10kW Capacity – Suitable for heavy-duty applications
Online Double Conversion UPS – Continuous clean power supply
0ms Transfer Time – No interruption during power failure
Pure Sine Wave Output – Safe for sensitive electronics
High Efficiency up to 95.5% – Energy saving operation
Wide Input Voltage Range (110–300VAC) – Works in unstable power areas
Power Factor 1.0 – Maximum usable power output
Intelligent Battery Management – Longer battery life
LCD Display Panel – Real-time monitoring
Multiple Protections – Overload, short circuit, overcharge
