Marsriva MR‑US6K‑H 6 kVA / 6 kW Online UPS | 192V Smart Double‑Conversion | 0ms Switchover
Pickup
Bagmati Province, Kathmandu, New Road
Delivery
17 Feb - 19 Feb 2 - 3 day(s)
रु. 150
Secure Shopping
We are committed to protecting the security of your information
Payment
Cash on Delivery Available
| Brand | : | Marsriva |
|---|---|---|
| Model | : | MR‑US6K‑H |
| Rated Capacity | : | 6 kVA / 6 kW |
| Output Voltage | : | 208 / 220 / 230 / 240 VAC (settable) |
| Output Frequency | : | 50 / 60 Hz ± 0.1 % (sync to mains, battery mode ±1 %) |
| Output Harmonic Distortion | : | ≤ 2 % THD (linear load), ≤ 5 % THD (non‑linear load) |
| Output Power Factor | : | 1.0 |
| Switching Time | : | AC Mode to Battery Mode: 0 ms; AC to Bypass: 4 ms (typical) |
| UPS Type | : | Double‑conversion On‑Line |
| Waveform Type | : | Pure Sine wave |
| Rated Input Voltage | : | 208 – 240 VAC |
| Input Voltage Range | : | 110 – 300 VAC @ < 50 % load; 176 – 280 VAC @ 100 % load |
| Input Frequency | : | 50 / 60 Hz ± 6 Hz (default), ± 10 Hz adjustable |
| Input Power Factor | : | ≥0.99 |
| Load Efficiency (AC Mode) | : | Up to 95.5 % (max) |
| Load Efficiency (Battery Mode) | : | Up to 94.8 % (full load, with external batteries) |
| Battery Type | : | Lead‑acid battery (external, user‑supplied) |
| Battery Voltage | : | 192 – 240 VDC (external battery bank configuration) |
| Charging Current | : | 1–12 A (settable) |
| Form Factor | : | Rack / Tower convertible type |
| Dimension (WHD mm) | : | 438 × 88 × 385 |
| Net Weight (kg) | : | Approx. 9.5 kg |
| Communication Interface | : | RS232, USB, EPO, SNMP (optional), Dry‑contact (optional), Maintenance connector (optional) |
| Control Panel | : | Multifunction LCD status and control console |
| Alarm | : | Alarm every 8 s in battery mode / Alarm for low battery every second / Alarm on overload every second |
| Protection | : | Short‑circuit, Overload, Overcharge and Overdischarge protection |
| Operating Temperature | : | 0 °C – 40 °C |
| Storage Temperature | : | –15 °C – 60 °C (battery: 0 °C – 40 °C) |
| Relative Humidity | : | 20 – 95 % (non‑condensing) |
| Audible Noise | : | < 50 dB @ 1 meter from surface |
Marsriva MR‑US6K‑H is a 6 kVA / 6 kW online UPS with smart double-conversion technology that delivers pure sine wave power, instant 0 ms switchover, and wide input voltage tolerance. Engineered for data centers, servers, and mission-critical systems, it provides reliable, continuous backup with intelligent battery management and full protection against overload, short-circuit, and voltage instability.
